★ 执行标准: DIN72551-6/1996
★ 导体规格:正规绞合,镀锡或裸铜丝
★ 聚氯乙烯绝缘
★ 绝缘厚度均匀 易剥 易裁
★ 耐油 耐热 耐磨损
★ 用于汽车内部连线 具高柔软性 高机械强度 耐高温环境使用
| Conductor | Finished product | Maximum Resistance at 20℃ | |||
| Cross Sectional Area | NO.of Cond | Insulation Thick. | Outside Diameter | Weight | |
| mm2 | No./mm | mm | mm | kg/km | Ω/km |
| 0.22 | 7/0.21 | 0.3 | 1.20 | 3.52 | 84.80 |
| 0.35 | 7/0.26 | 0.3 | 1.30 | 4.79 | 52.00 |
| 0.5 | 19/0.19 | 0.3 | 1.60 | 7.07 | 37.21 |
| 0.75 | 19/0.23 | 0.3 | 1.90 | 10.19 | 24.70 |
| 1 | 19/0.26 | 0.4 | 2.10 | 12.79 | 18.50 |
| 1.5 | 19/0.32 | 0.4 | 2.40 | 18.31 | 12.70 |
